The 2017 aluminum alloy material belongs to the medium tough aluminum, due to the material has a strong timeliness reinforcement effect, it has high hardness and strength after solid -soluble time, and also has excellent processing process performance. It can be processed into semi -finished products such as various wires and rods, and is widely used in stress structural components that produce medium loads, such as rivets, fasteners etc.
Why choose Chalco 2017 aluminum alloy wire rod for rivets?
Chalco Aluminum is a company that integrates precision detection of precision testing such as melting, squeezing, and refined aluminum manufacturing.
Chalco Aluminum can provide excellent quality of 2017 aluminum alloy wire for fasteners using and high -quality technical services on the market, and have deep knowledge of how to support customers to deal with future challenges.
We have a whole set of domestic advanced rivets in China to develop, detect, and analyze instruments to provide guarantees for the development efficiency of new products and accelerate the transformation of scientific and technological achievements. In addition, our R & D & innovation and verification capabilities can help enhance the competitiveness of customers by saving the time and costs of new product development and marketing.
We have passed the AS9100 certification required by the aviation industry, the IATF16949 certification required by the automotive industry, etc., provides a strong guarantee for the quality of the aluminum alloy pole of the rivet for rivets produced by our company.
Chalco's brand represents quality, delivery ability and good reputation. With leading technology and global competitive products, we can continue to develop with customers in the future.
The specification of 2017 aluminum alloy wire for fasteners
| Size | 1.6-10.0mm |
| Temper | O, H13, T4 |
| Size Tolerance | ±0.02mm |
| Weight Coil | Above 50KGs |
| Function | make Solid rivets |
The chemical composition of the 2017 aluminum alloy wire rod for fasteners
| Element | Composition % |
| Si | 0.20-0.8 |
| Fe | 0.70 |
| Cu | 3.5-4.5 |
| Mn | 0.40-1.0 |
| Mg | 0.40—0.8 |
| Cr | 0.10 |
| Zr | - |
| Zn | 0.25 |
| Ti | 0.15 |
| Al | Remainder |
The mechanical properties of the 2017 aluminum alloy wire for fasteners using
| Alloy | Supply temper | Sample temper | Diameter mm | Mechanical properties | |||
| Tension Strength Rm Mpa | Yield Strength R p0.2 Mpa | Elongation after break/% | |||||
| A100 mm | A250 mm | ||||||
| Not less than | |||||||
| 2017 | O | O | 1.6-10.0 | ≤240 | - | - | - |
| H13 | H13 | 205-275 | - | - | - | ||
| T4 | T4 | 380 | 220 | 10 | - | ||
The shear strength and riveting properties of 2017 aluminum rod for rivets
| Alloy | Temper | Sample Temper | Diameter mm | Shear strength τ Mpa | Riveting property | |
| Protrusion height of sample ratio to diameter | Riveting test time | |||||
| 2017 | O H13 | T4 | 1.6-25 | ≥225 | - | - |
The dimension tolerance of 2017 aluminium wires for rivets
| Diameter | Tolerance allowed | |||
| Grade A | Grade B | Grade C | Grade D | |
| ≤1.6 |
+0.000 -0.015 |
+0.015 -0.015 |
±0.015 |
+0.00 -0.04 |
| ＞1.6-4.0 |
+0.000 -0.025 |
+0.025 -0.015 |
±0.025 |
+0.00 -0.05 |
| ＞4.0-6.0 |
+0.000 -0.030 |
+0.025 -0.025 |
±0.040 |
+0.00 -0.08 |
| ＞6.0-10.0 |
+0.000 -0.040 |
+0.050 -0.025 |
±0.060 |
+0.00 -0.12 |
The appearance quality of 2017 aluminum alloy rod and wire for rivets
| Defect name | Technical requirement |
| Fastener aluminum wire | |
| Cracks, burrs, peeling, air bubbles, bumps, dents, scratches, triangular mouths, metal press-in, non-metal press-in and surface corrosion | Not allowed |
| Scuffs, scratches, bumps | Allowable depth does not exceed half of the negative deviation value |
| Oil spots | Allowed |
Characteristics of the 2017 aluminum alloy wire rod for rivets
High intensity: 2017 aluminum alloy has a strong timeliness reinforcement, and has high hardness and strength after solid solution.
Good thermal resistance: the heat resistance of the 2017 Aluminum wire for rivets using is good, and it shows good stability and performance in high temperature environments. It is not easy to soften, melt or lose its mechanical strength and chemical stability.
Excellent processing process performance: 2017 Aluminum Alloy Wire Rod for fasteners have excellent processing process performance. It can create various shapes and specifications of willow nails such as squeezing and pull -ups.
Light quality: The density of aluminum alloy is low, which is lighter than other metals such as steel, so the fastener of the 2017 aluminum alloy manufacturing helps reduce the overall weight.
Corrosion resistance: the 2017 Aluminum wire for rivets using have excellent corrosion resistance, making it more durable in humid and corrosive environments.
Wide application range: 2017 Aluminum Alloy Wire Rod for fasteners are suitable for multiple fields, such as aerospace, automobiles, ships, electronics, etc., especially in cases that need lightweight and high intensity.
Key points for buying the 2017 aluminum alloy rod and wire for rivets
Material specifications: confirm the specific material specifications of aluminum poles, including alloy types, ingredients, hardness, etc. Different alloys and specifications are suitable for different application scenarios.
Heat resistance: if you need to use aluminum poles in rivets in high temperature environments to ensure that it has enough heat resistance to avoid softening or loss of strength during use.
Power and hardness: according to your needs, choose an appropriate strength and hardness aluminum pole to ensure that it can meet the expected connection or support requirements.
Size and shape: according to your specific application, select the appropriate size and shape of aluminum poles to ensure that it matches with rivets.
Surface treatment: understand whether the aluminum pole is treated with special surface treatment to improve its corrosion resistance and appearance quality.
Quality certification: make sure the purchased aluminum poles meet relevant quality standards and certification requirements to ensure product quality and reliability.
Supplier's reputation: choose good reputation suppliers or manufacturers to ensure product quality and after -sales service.
The packaging method of the 2017 aluminum alloy wire rod for rivets
- Double fiber cloth packing
- Wooden box packing
- Eye to sky wooden pallet packing
Application of 2017 aluminium alloy wire for rivet
Chalco Aluminum produced in 2017 Aluminum alloy wire rod for rivets. The product tolerance is very rigorous. The specifications cover 1.6-10.0mm. The single volume weight can be produced according to customer requirements.
The 2017 aluminum alloy wire for fasteners are used to produce various types of fasteners, especially high -strength solid rivets, and are widely used in the fields of machinery, military, aerospace, ships, and automobiles. On the Boeing series, rivets used to connect the fuselage skin are basically rivets produced with 2017 aluminum alloy wires and rods.
