Why choose Chalco aluminum rivets wire?
Authentication
Chalco products are manufactured in our state-of-the-art facility using a strict quality and environmental management system that is ISO certified, IATF16949 certification for the automotive industry, etc.
Production strength
Production and management in accordance with the international industry standards to ensure a long service life.
Production standard
GB/T 3195-2023
The specification of aluminum rivets wire
| Size | 1.6-10.0mm |
| Temper | O |
| Surface quality | No cracks, no burrs, no skinning, no bubbles, no bumps, no dents on the surface, No scratches, no triangular opening, no metal indentation, no non-metal indentation and no surface corrosion, oil spots, etc. |
5056 5056A rivet wire diameter deviation
| Diameter | Allowable deviation | |||
| A grade | B grade | C grade | D grade | |
| ＞1.6-4.0 |
+0.000 -0.025 |
+0.025 -0.015 |
±0.025 |
+0.00 -0.05 |
| ＞4.0-6.0 |
+0.000 -0.030 |
+0.025 -0.025 |
±0.040 |
+0.00 -0.08 |
| ＞6.0-10.0 |
+0.000 -0.040 |
+0.050 -0.025 |
±0.060 |
+0.00 -0.12 |
Chemical component of Chalco aluminum rivets wire
| Element | Composition % | |
| 5056 | 5056A | |
| Al | Rest | Rest |
| Mg | 4.5-5.6 | 5.1-5.9 |
| Mn | 0.25 | 0.15 |
| Cr | 0.25 | 0.10 |
| Cu | 0.10 | 0.10 |
| Fe | 0.40 | 0.35 |
| Zn | 0.25 | 0.25 |
| Ti | 0.20 | 0.20 |
| Si | 0.25 | 0.25 |
| V | 0.05 | 0.05 |
| Zr | 0.10 | |
5056 5056A mechanical properties of riveted aluminum wire
| Alloy | Supply temper | Sample temper | Diameter mm | Mechanical properties | |||
| tensile strength Rm MPa | yield strength Rp0.2 MPa | Elongation % | |||||
| A100mm | A250mm | ||||||
| No less than | |||||||
| 5056 | O | O | ≤320 | — | — | — | |
Characteristics of Chalco 5056 5056 aluminum rivets
High strength: 5056 5056A Rivet Aluminum Wire has high strength, allowing it to withstand high loads and pressures in joining and fastening applications.
Corrosion resistance: aluminum alloys have good corrosion resistance, especially 5056 5056A aluminum alloy, which is suitable for use in wet, high humidity or corrosive environments, and is therefore widely used in aerospace, automotive and marine engineering.
Light weight: aluminum is a lightweight metal, compared to materials such as steel, 5056 5056A Rivet Aluminum Wire has a lower density, which helps reduce the weight of the overall structure.
Easy to process: 5056 5056A Rivet Aluminum Wire is easy to process and form, so manufacturers can produce rivets of different sizes and shapes according to specific needs.
Weldability: 5056 5056A aluminum alloy has good weldability and can be welded to other aluminum alloys or the same material, thus providing greater design flexibility.
Suitable for high temperature environments: 5056 5056A aluminum alloy can maintain its properties at relatively high temperatures, so the strength of the rivet connection will not be significantly reduced in some high temperature working environments.
Overall, 5056 5056A riveted aluminum wire is an excellent riveting material for engineering applications requiring high strength, corrosion resistance and lightweight properties. It is widely used in aerospace, automotive manufacturing, marine and offshore engineering.
Precautions for purchasing aluminum rivets wire
Material certification
Ensure that the purchased aluminum rivets wire meets relevant standards and obtains a qualified material certification certificate.
Specification requirements
Select the appropriate specification, size and shape according to actual needs to ensure that the purchased aluminum rivets wire can meet the specific aluminum rivets wire manufacturing requirements.
Surface quality
Check whether the surface of the purchased aluminum rivets wire is smooth, free of cracks, wear, oxidation or other surface defects, to ensure that the surface quality of the aluminum rivets wire meets the requirements.
Supplier reputation
Choose a reputable and experienced supplier to purchase to ensure that the purchased aluminum rivets wire is reliable in quality, reasonable in price and timely in delivery.
Storage requirements
Pay attention to the storage requirements of the aluminum rivets wire, keep it dry, avoid moisture, mechanical impact or other damage.
In short, when purchasing aluminum rivets wire, you need to pay attention to material certification, specification requirements, surface quality, supplier reputation and storage requirements, etc., to ensure that the purchased aluminum rivets wire are reliable in quality and meet the requirements.
Applications of Chalco aluminum rivets wire
5056 and 5056A are two aluminum alloys that share many similarities when it comes to riveting aluminum wire applications. Here are some common uses of these two aluminum alloys in riveted aluminum wire applications:
Aerospace industry: 5056 and 5056A riveted aluminum wire are widely used in the aerospace industry. Their high strength and excellent corrosion resistance make them important connecting elements for aircraft and aircraft components.
Automotive manufacturing: automotive manufacturing is also an important application area for 5056 and 5056A rivet aluminum wire. These rivets are commonly used in the assembly of automotive bodies and structures, as aluminum alloys reduce vehicle weight and improve fuel efficiency.
Railroad transportation: 5056 and 5056A rivet aluminum wire is also used in the production of railroad vehicles, such as the manufacture and repair of train cars.
Shipbuilding: because 5056 and 5056A riveted aluminum wires are corrosion-resistant, they are often used in the construction of ships, including the connection of hulls, planks and decks.
Construction: these riveted aluminum wires can be used for the assembly and connection of building structures, such as bridges, building columns, etc.
Chemical and marine engineering: the corrosion resistance of 5056 and 5056A riveted aluminum wire makes it suitable for connection and fixing applications in chemical plants and marine engineering.
