What is 2618 aluminum plate?

2618 aluminum plate is a high-strength aluminum alloy plate containing copper and magnesium. It's characterized by high strength and toughness.

What are the features of 2618 aluminum plate?

2618 aluminum plate features include: * High strength and toughness * Good machinability * Excellent weldability * Good electrical and thermal conductivity * Good corrosion resistance

What are the applications of 2618 aluminum plate?

2618 aluminum plate is used in aerospace, defense, automotive, mold, and mechanical manufacturing industries.

What are the specific performance parameters of 2618 aluminum plate?

Performance parameters include: * Tensile Strength (MPa): 480 * Yield Strength (MPa): 360 * Brinell Hardness (HB): 130

High Ductility 2618A T61 T351 T851 Aluminum Plate

2618A is a heat-treatable Al-Cu-Mg-Ni-Fe alloy known for its high heat resistance, with a usage temperature range of 200-300°C. It exhibits good cold and hot working properties, excellent ductility, moderate welding performance, making it suitable for manufacturing components intended for use at elevated temperatures. Applications include automotive turbochargers, aerospace components, and defense and military components.

2618A aluminum plate standard

Aluminum 2618 T61 AMS 4132 Forged plate

Aluminium Alloy DTD 5070B 2618-TF Clad Sheet

AIMS 03-04-036 Aluminium 2618A H28(T62) clad Sheet

BAEM 4049 Aluminium 2618A F(T62) clad Sheet

EN 2123 Aluminium 2618A T351 T851 plate

3.1924 Aluminium 2618A T651 plate

DTD 5070 Aluminium 2618A T6 clad Sheet

Get A Quote

Hot selling sizes of Chalco 2618A T61 forged aluminum plate

Description	Temper	Thickness/mm	size/mm
3.94" 2618 T61 Alu Forged Plate AMS 4132	T61	100	1000*2000
5.91" 2618 T61 Alu Forged Plate AMS 4132	T61	150	1000*2000
7.87" 2618 T61 Alu Forged Plate AMS 4132	T61	200	1000*2000
9.84" 2618 T61 Alu Forged Plate AMS 4132	T61	250	1000*2000
11.81" 2618 T61 Alu Forged Plate AMS 4132	T61	300	1000*2000
13.78" 2618 T61 Alu Forged Plate AMS 4132	T61	350	1000*2000
15.75" 2618 T61 Alu Forged Plate AMS 4132	T61	400	1000*2000
17.72" 2618 T61 Alu Forged Plate AMS 4132	T61	450	1000*2000
19.69" 2618 T61 Alu Forged Plate AMS 4132	T61	500	1000*2000
21.65" 2618 T61 Alu Forged Plate AMS 4132	T61	550	1000*2000
23.62" 2618 T61 Alu Forged Plate AMS 4132	T61	600	1000*2000

Hot selling sizes of Chalco 2618A aluminum plate

Description	Temper	Thickness/in	Thickness/mm	size/mm
0.04" 2618 T6 AL Cald Sheet DTD 5070B 1520*3020	T6	0.04	1	1520*3020
0.08" 2618 T6 AL Cald Sheet DTD 5070B 1520*3020	T6	0.08	2	1520*3020
0.12" 2618 T6 AL Cald Sheet DTD 5070B 1520*3020	T6	0.12	3	1520*3020
0.16" 2618 T6 AL Cald Sheet DTD 5070B 1520*3020	T6	0.16	4	1520*3020
0.2" 2618 T6 AL Cald Sheet DTD 5070B 1520*3020	T6	0.2	5	1520*3020
0.24" 2618 T6 AL Cald Sheet DTD 5070B 1520*3020	T6	0.24	6	1520*3020
0.04" 2618 T62 AL Cald Sheet ASN-A-3043 1250*2500	T62	0.04	1	1250*2500
0.08" 2618 T62 AL Cald Sheet ASN-A-3043 1250*2500	T62	0.08	2	1250*2500
0.12" 2618 T62 AL Cald Sheet ASN-A-3043 1250*2500	T62	0.12	3	1250*2500
0.16" 2618 T62 AL Cald Sheet ASN-A-3043 1250*2500	T62	0.16	4	1250*2500
0.2" 2618 T62 AL Cald Sheet ASN-A-3043 1250*2500	T62	0.2	5	1250*2500
0.24" 2618 T62 AL Cald Sheet ASN-A-3043 1250*2500	T62	0.24	6	1250*2500
0.28" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	0.28	7	1520*3020
0.31" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	0.31	8	1520*3020
0.35" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	0.35	9	1520*3020
0.39" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	0.39	10	1520*3020
0.47" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	0.47	12	1520*3020
0.55" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	0.55	14	1520*3020
0.59" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	0.59	15	1520*3020
0.63" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	0.63	16	1520*3020
0.71" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	0.71	18	1520*3020
0.79" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	0.79	20	1520*3020
1.18" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	1.18	30	1520*3020
1.57" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	1.57	40	1520*3020
1.97" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	1.97	50	1520*3020
2.36" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	2.36	60	1520*3020
2.76" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	2.76	70	1520*3020
3.15" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	3.15	80	1520*3020
3.54" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	3.54	90	1520*3020
3.94" 2618 T651 Aluminum Plate DIN 3.1924 1520*3020	T651	3.94	100	1520*3020
0.28" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	0.28	7	1520*3020
0.31" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	0.31	8	1520*3020
0.35" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	0.35	9	1520*3020
0.39" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	0.39	10	1520*3020
0.47" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	0.47	12	1520*3020
0.55" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	0.55	14	1520*3020
0.59" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	0.59	15	1520*3020
0.63" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	0.63	16	1520*3020
0.71" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	0.71	18	1520*3020
0.79" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	0.79	20	1520*3020
1.18" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	1.18	30	1520*3020
1.57" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	1.57	40	1520*3020
1.97" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	1.97	50	1520*3020
2.36" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	2.36	60	1520*3020
2.76" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	2.76	70	1520*3020
3.15" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	3.15	80	1520*3020
3.54" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	3.54	90	1520*3020
3.94" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	3.94	100	1520*3020
4.33" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	4.33	110	1520*3020
4.72" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	4.72	120	1520*3020
5.12" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	5.12	130	1520*3020
5.51" 2618 T351 Aluminum Plate EN 2123 1520*3020	T351	5.51	140	1520*3020
0.28" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	0.28	7	1520*3020
0.31" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	0.31	8	1520*3020
0.35" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	0.35	9	1520*3020
0.39" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	0.39	10	1520*3020
0.47" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	0.47	12	1520*3020
0.55" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	0.55	14	1520*3020
0.59" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	0.59	15	1520*3020
0.63" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	0.63	16	1520*3020
0.71" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	0.71	18	1520*3020
0.79" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	0.79	20	1520*3020
1.18" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	1.18	30	1520*3020
1.57" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	1.57	40	1520*3020
1.97" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	1.97	50	1520*3020
2.36" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	2.36	60	1520*3020
2.76" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	2.76	70	1520*3020
3.15" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	3.15	80	1520*3020
3.54" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	3.54	90	1520*3020
3.94" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	3.94	100	1520*3020
4.33" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	4.33	110	1520*3020
4.72" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	4.72	120	1520*3020
5.12" 2618 T851 Aluminum Plate EN 2123 1520*3020	T851	5.12	130	1520*3020

If the above inventory does not meet your specifications, you can contact us directly for customization or check the specific production capabilities below.Quick Quote

Specifications of Chalco 2618A Aluminum Plate

Hot selling status	T61 , T62 , T6 , T651 , T351 , T851
Equivalent name	EN AW-2618, A92618, AA 2618; AlCu2Mg1.5Fe1Ni1; A-U2GN, AU2GN; AlCu2Mg2Ni; LW3.1924; H16, Hiduminium RR; DTD717A;
2618A clad aluminum sheet	Thickness:0.008”-0.24”(0.2mm-6mm)	Width:35.4”-104”(900mm-2650mm)
2618A clad aluminum plate	Thickness:0.24”-9.84”(6mm-250mm)	Width:39.4”-150”(1000mm-2650mm)
2618A aluminum plate	Thickness:0.24”-3.94”(6mm-250mm)	Width:35.4”-104”(900mm-2650mm)
2618A T61 aluminum forged plate	Thickness:3.94”-24”(100mm-600mm)	Width:39.4”-150”(1000mm-2000mm)
length	Max 6m, Fix & Cut Length or Customized
Lamination	Black and white film, blue film, transparent film (film thickness: 50 microns, 80 microns)
surface treatment	Bright, polished, hair line, brush, sand blast, checkered, embossed, etching, etc.

Chemical composition of EN-AW 2618A aluminum plate

Element	Composition %
Si	0.10-0.25
Fe	0.9-1.3
Cu	1.9-2.7
Mn	-
Mg	1.3-1.8
Ni	0.9-1.2
Zn	0.1
Ti	0.04-0.10
Other	0.2
Al	Rem

The 2618A aluminum alloy is known for its relatively higher content of iron (Fe) and nickel (Ni). Iron is typically an impurity in aluminum alloys, but in 2618A, it is deliberately added in significant amounts to enhance strength, particularly at high temperatures, with minimal impact on electrical performance. The addition of nickel serves to reinforce mechanical strength at high temperatures and reduce thermal expansion, although it may increase the susceptibility of certain alloys to pitting corrosion.

Physical properties of the A92618 aluminum plate

Temper	Specified thickness/mm		Tensile strength Rm/MPa		Yield strength Rp0.2/MPa		Elongation min.%
Temper	over	up to	min.	max.	min.	max.	A50 mm	A
T851	6	12.5	420	-	375	-	5	-
T851	12.5	40	420	-	375	-	-	5
T851	40	80	410	-	370	-	-	5
T851	80	100	405	-	365	-	-	4
T851	100	140	395	-	360	-	-	4

Chalco hot selling product recommendations

2618 aerospace aluminum plate

2618 aluminum bar

2618 aluminum forging

2024 aluminum plate

2014 aluminum plate

2219 aluminum plate

7075 aluminum plate

7050 aluminum plate

7475 aluminum plate

Questions you might want to know about EN-AW 2618A aluminum sheet

What are the hot-selling products of EN-AW 2618A aluminum sheet?

EN AW-2618A T6 Aluminum Cald Sheet
EN AW-2618A T62 Aluminum Cald Sheet
A92618A T651 Aluminum plate
A92618A T351 Aluminum plate
EN AW-2618A T851 Aluminum plate
A92618A T61 Aluminum Forged Plate

Custom Aluminum plate

What characteristics does A92618 aluminum plate exhibit?

Excellent high-temperature performance
Extremely high strength
High ductility
Good machinability
Resistance to atmospheric corrosion

Quick Quote

What characteristics does A92618 aluminum plate exhibit?

In which application areas does EN-AW 2618A aluminum sheet excel?

Aerospace components
Defense components
High-tech applications
Racing pistons
Rotating aircraft parts

Purchase Now

application of 2618 plate

What are the advantages of Chalco as a supplier of 2618A aluminum plate?

Chalco boasts three forging production lines, including 1500-ton, 1000-ton, 630-ton, and 160-ton presses, as well as mold manufacturing and design equipment, along with comprehensive testing facilities. The company provides full-service support from product design to engineering, manufacturing, testing, and validation.

Equipped with an advanced German SMS (1+4) 4500mm hot continuous rolling production line, Chalco features state-of-the-art Siemens electrical configuration, an online IMS curvature meter from Germany, and closed-loop control of thickness and plate shape. The hot rolling mill is equipped with hydraulic adjustment systems, CVCplus, work roll bending, multi-zone cooling systems, and temperature control systems. It also includes light and heavy shears, slitters, edge trimmers, coilers, scrap transportation systems, and smoke purification systems.

advantages of Chalco as a supplier of 2618A aluminum plate

Chalco's advanced production lines and manufacturing technologies ensure the maximum quality of plate shape and appearance, mitigating various common quality issues. The competitive pricing directly from the source manufacturer and one-stop supply alleviate your concerns. All products undergo quality system certifications such as ISO 9001, GJB 9001, AS9100, TS16949, and hold Nadcap (NonDestructive/Heat/Materials Testing) certificates. Customization according to customer requirements for Japanese, European, American standards, and more is also available.
